Sidewall Magnetic Bracket Antenna Mounting
ANTENNA BRACKETING
Sidewall Antenna Bracket
Use: Magnetic antenna mounting on steel sidewalls and structures
Common Antenna: radio, telemetry, wisp/internet, cellular
Number of magnets: 124
Can be custom designed in size for different antenna
applications
Calculated vertical pull force: 5,580 lbs
Calculated sheer pull force: 3,472 lbs
Dimensions: 50” H X 20” W
Applied and removed to steel surface with patented
HoverBolt System (detail below)
Incorporated patented FlexTechnology (detail below)
conforms and flexes to any diameter of steel surface,
convex or concave, greater than 18”
Incorporated HoverBolt Technology available with
Sidewall Brackets for ease of installation and removal
Commonly paired with Estech Talon Series Magnetic
Bracket for cable fastening
Custom mast sizes available per order for antenna
compatibility and hardware
Designed for antennae up to 125 lbs*
304 Stainless Steel
Monolithic Frame
FlexTM Technology
--Patent Applied--
The new, yet proven Flex technology allows all Estech brackets to confirm to a range of convex, concave, and flat steel surfaces without measurements or worry. The magnetic pads are able to pivot to the tangency of the surface profile automatically during installation, supported by stainless steel “tendons” which have been tested to withstand over 160 bends of 90 degrees.
HoverboltTM Technology
--Patent Applied--
As Estech’s magnetic systems grew in size and strength, a new way of controlling the
installation , position, and removal was needed. The HoverboltTM technology features a series of bolts as a scratch resistant stand-off gap, temporarily reducing the magnetic force to the surface until the installer is ready for the final placement. HoverboltsTM are also used to lift and release the magnetic systems with control.
