TELECOM PRODUCT CATALOG SUMMER 2025 785-806-5211 | [email protected] estechmagnetics.com
ESTECHMAGNETICS.COM | 785-806-5211 2 ESTECH MAGNETICS PRODUCTS 2025 Product Guide What is FLEX™ Technology? .............................................................................................................. 4 What is the HoverBOLT™ System? .................................................................................................... 5 Standardized Magnetic Testing Procedure (SMTP) ......................................................................... 6 Talon2-FLEX (8 magnets) ...................................................................... 10 Application: water towers, wind turbines, and monopoles Size: 7.3” L X 6.4” W X 2” H HaloMAG Series ..................................................................................... 8 Application: water towers Talon3-FLEX(12 magnets) .................................................................... 12 Application: water towers, wind turbines, and monopoles Size: 10.2” L X 9.4” W X 2.4” H Talon6-FLEX(18 magnets) .................................................................... 14 Application: water towers, wind turbines, and monopoles Size: 19.2” L X 9.4 W X 2.5” H Mono 4-FLEX(12 magnets) ..................................................................16 Application: faceted monopoles, water towers, and wind turbines Size: 13.7” L X 6.5” W X 1.8” H
ESTECHMAGNETICS.COM | 785-806-5211 3 ESTECH MAGNETICS PRODUCTS 2025 Tripod MAX Magnetic Bracket ......................................................................................................... 30 Product Installation and Use Photo Gallery .................................................................................... 31 Mono6-FLEX(16 magnets) ...................................................................18 Application: faceted monopoles, water towers, and wind turbines Size: 13.7” L X 6.5” W X 1.8” H Sidewall Series (54 & 72) ...................................................................... 20 Application: faceted monopoles, water towers, and wind turbines MagFOOT™ Series (170, 248 & 322).................................................... 24 Application: water towers Proprietary & Confidential Statement: This document and the information disclosed within, including the document structure and contents, are confidential and the proprietary property of Estech LLC and are protected by patent, copyright and other proprietary rights. ESTECHMAGNETICS.COM | 785-806-5211
ESTECHMAGNETICS.COM | 785-806-5211 4 ESTECH MAGNETICS PRODUCTS 2025 What is FLEX™ Technology? FLEX™ Technology allows Estech’s Talon brackets to conform to a range of convex, concave, and flat surfaces without measurements. The magnetic pads are able to pivot to the tangency of the surface profile automatically during installation, supported by stainless steel “tendons” which allow the entire bracket body to be monolithically constructed. This compliant mechanism technology brings out the capability of lamina emergence and the strength of neodymium magnets. A depiction of the flexibility of the FLEX™ Technology mechanism within a Talon3-FLEX. An example of a Talon3-FLEX on a convex surface; note the position of the magnets. An example of a Talon3-FLEX on a flat surface; note the position of the magnets. An example of a Talon3-FLEX on a concave surface; note the position of the magnets. A depiction of the flexibility of the FLEX™ Technology mechanism within a Sidewall54-FLEX mount.
ESTECHMAGNETICS.COM | 785-806-5211 5 ESTECH MAGNETICS PRODUCTS 2025 What is the HoverBOLT™ System? Estech’s range of medium and large magnetic strength brackets now feature patented HoverBOLT™ setting and removal technology. As Estech’s magnetic systems grew in size and strength, a new way of controlling the installation, positioning, and removal was needed. The HoverBOLT™ technology features a series of nylon tipped bolts as a scratch-resistant stand-off gap, temporarily reducing the magnetic force to the surface until the installer is ready for final placement. HoverBOLTS™ are also used to lift and release the magnetic systems with control. Placement, adjustment, and removal are now commanded and controlled with a ½” socket wrench even on the record-setting 70,000 lb magnetic force corral systems.
ESTECHMAGNETICS.COM | 785-806-5211 6 ESTECH MAGNETICS PRODUCTS 2025 Standardized Magnetic Testing Procedure (SMTP): Testing Program and Specifications Written by: Eric Stechmann, Estech LLC Purpose: A precise, repeatable method for determining real-world bracket embodiment performance from industrial magnetics is desired within the telecommunications industry. This testing procedure uses average circumstances seen in installation locations and provides the ability to test tension forces on a variety of angular point locations within the magnetic bracket body. This test will better allow the industry to record and predict real-world bracket system performance in average circumstances prior to deployment in industrial outdoor settings. A flat plane of steel which is analogous to AWWA and NACE standards can be produced in a modular form on a facility concrete floor for the purposes of this test. Materials: • 3 feet by 3 feet square mild steel plates with ½” bolt locations • Polyurethane coatings applied within 10-12 mils onto the blasted, clean surface of the plate material • 5,000 pound load cell, traceable calibration, with a remote digital interface • Digital angle gauge • One or multiple video camera locations to document the procedure • One video camera location to document the maximum tension (pounds) prior to performance yield • Gantry system that is capable of floor-parallel and floorperpendicular tension up to 5,000 pounds • Gantry system pivot cam pully system that is able to slide and fix into place the exact position of cable placement • Pulling tension force may be induced by (hand, ratchet cable binder, winch or vehicle hitch) • All safety and PPE materials and practices Tested Load Requirement Each magnetic bracket embodiment will be tested along a combination of tensile directions. Tension attachment locations shall be recorded and height above steel surface also recorded. • X-Axis 0 Degrees • X-Axis 30 Degrees • X-Axis 45 Degrees • X-Axis 60 Degrees • Y-Axis 0 Degrees • Y-Axis 30 Degrees • Y-Axis 45 Degrees • Y-Axis 60 Degrees • 90 Degrees on centroid of magnetism Yield Definition Magnetic force will be tested to the yield condition of the bracket embodiment. For the purposes of this testing procedure, the yield point will be defined as the average maximum tension force experienced which induces a kinetic deflection along and within .25 inches of surficial movement along the length of travel. A marking scale can help with visualizing this .25 inch reference such as a length of contrasting tape. Up to three tests may be necessary to produce a repeatable, clear average of tensile force. For the purposes of this testing procedure, the yield point will be defined as the maximum tension force experienced at the vertical (90 degree) pull off breakpoint experienced if tested perpendicular to the floor. Reporting Results from these calibrated tension forces will be aggregated into a spreadsheet with each procedure as the vertical column and the bracket embodiment as the row.
ESTECHMAGNETICS.COM | 785-806-5211 7 ESTECH MAGNETICS PRODUCTS 2025 Important Notes This test is focused on creating an analogue of a real-world scenario into a facility that is able to produce tension into a focused and calibrated area. The steel plates are specifically made to National AWWA water tower coatings standards with 10-12 mils of coating thickness and a coefficient of friction that is similar to that experienced on most water towers. A NACE and AWWA compliant zincrich primer is advised to be applied to the steel prior to application of a polyurethane coating system. Depicting a horizontal tipping breakpoint at about 3 feet above the floor. This setup is adjustable. Depicting a horizontal shear breakpoint at about 3 inches above the floor. This setup is adjustable. Depicting an angular tipping breakpoint at about 1 foot above the floor. This setup is adjustable. Depicting a vertical pull-off breakpoint at centroid to magnetism. This setup is adjustable.
ESTECHMAGNETICS.COM | 785-806-5211 8 ESTECH MAGNETICS PRODUCTS 2025 HaloMAG Series - Magnetic Roof Corral 25’ Diameter Magnetic HaloMAG Roof Corral Part Number: HLMG25-2112-H • Roof corral steel structure, made from mild steel, zinc coated, and coated in choice of Tank White or Tank Blue • 16 Magnetic Feet (MagFOOT) made of 304 stainless steel with N42 rare earth neodymium magnets • Drone photogrammetry and/or physical site inspection for measurements • Does not include: MA from Engineering firm, if necessary • Does not include: Freight from Missouri to requested drop location 35’ Diameter Magnetic HaloMAG Roof Corral Part Number: HLMG35-2640-H • Roof corral steel structure, made from mild steel, zinc coated, and coated in choice of Tank White or Tank Blue • 20 Magnetic Feet (MagFOOT) made of 304 stainless steel with N42 rare earth neodymium magnets • Drone photogrammetry and/or physical site inspection for measurements • Does not include: MA from Engineering firm, if necessary • Does not include: Freight from Missouri to requested drop location
ESTECHMAGNETICS.COM | 785-806-5211 9 ESTECH MAGNETICS PRODUCTS 2025
ESTECHMAGNETICS.COM | 785-806-5211 10 ESTECH MAGNETICS PRODUCTS 2025 Talon2-FLEX Part Number: T2F-08-H Uses Magnetic fastening for cable and conduit management on indoor and outdoor steel surfaces • Common steel surfaces • Water towers • Monopoles • Wind Turbines Features • FLEX™ magnetic brackets allow the magnetic arms to pivot to a variety of surfaces without tooling • Flat • Convex (12” diameter or larger tubing) • Concave (36” or larger tubing) • Angled (see geometry for compatibility) • Bracket body hosts multiple fastening options • Two (2) Snap-in/SnapStak® hanger locations, duplexing allowed within capacity • Three (3) 3/8” socket connections for conduit clamps, cable blocks, ground bars, or cabinets • Magnetic units: Eight (8) magnet units of N42 rareearth alloy composition. See calibrated testing matrix for yield-load values • HoverBOLT™ System, installed per customer request, allows bracket to be installed, adjusted and removed with command and control Material Specifications 7.3” L X 6.4” W X 2” H Weight: 2.29 lbs ASTM 304 Stainless Steel monolithic frame Vibratory tumble finish Spacing of bracket: Estech recommends a 5’ oncenter maximum spacing or observation of the cable manufacturer specification. In such case, the closer spacing will be the recommended value
ESTECHMAGNETICS.COM | 785-806-5211 11 ESTECH MAGNETICS PRODUCTS 2025 Magnetic Force Testing on Talon2-FLEX X&Y Axis Yield Definition Magnetic force is tested to the yield condition of the bracket embodiment. For the purpose of the calibrated testing procedure, the yield point is defined as the average maximum tension force experienced which induces a deflection along the given axis of up to .25 inches parallel to the tested steel surface. Z Axis Yield Definition The yield point is defined as the maximum tension force experienced at the vertical (90 degree / Z axis) pull of breakpoint experienced if tested perpendicular to the floor. Reporting Results from these calibrated tension forces are aggregated into a spreadsheet with each procedure as the vertical column and the axis in the horizontal column. Please see below table for product testing of the Talon2-FLEX magnetic bracket. Video of all tests further record and confirm performance data. Please refer to Estech’s Standardized Magnetic Testing Procedure Testing Program and Specifications document for further information. Table 1: Working Load Table — 2X Safety Factor Recommended by ESTECH Estech recommends a safety factor or 2X when the consumer load is compared to calibrated factory tested ultimate load data. This table below will aid in determining the correct magnetic bracket size for needed capacity. An on-center spacing of no more than 5 feet is specified on this magnetic bracket system. Table 2: Working Load Table — Performance Data Testing by ESTECH This magnetic bracket has been factory tested in a calibrated condition. Many factors influence the magnetic performance in outdoor settings such as; steel type and thickness, temperature, moisture, thickness of coating systems, coefficient of friction of coating system and direction of force. Estech has used 1/4” mild steel with a 10-12 mil AWWA compliant coating system at 70° Fahrenheit average at all stated axies and variable angular directions of tensile pull force (lbf). Magnetic force improves with; thicker steel, ferrous metal, thinner coatings, rougher coatings, colder temperatures at dry conditions. Estech formulated this calibrated test standard to best model conditions commonly seen on water tower and similar outdoor settings. Note: these are ultimate loads. Highest forces at a maximum displacement of .25” were recorded and averaged. The results are located in the table below. Table 1 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 71.5 lbf 66.5 lbf 70 lbf 75 lbf Y-Axis 73.5 lbf 66.5 lbf 69 lbf 76.5 lbf Z-Axis 105.5 lbf Table 2 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 143 lbf 133 lbf 140 lbf 150 lbf Y-Axis 147 lbf 133 lbf 138 lbf 153 lbf Z-Axis 211 lbf
ESTECHMAGNETICS.COM | 785-806-5211 12 ESTECH MAGNETICS PRODUCTS 2025 Talon3-FLEX Part Number: T3F-12-H Uses Magnetic fastening for cable and conduit management on indoor and outdoor steel surfaces • Common steel surfaces • Water towers • Monopoles • Wind Turbines Features • FLEX™ magnetic brackets allow the magnetic arms to pivot to a variety of surfaces without tooling • Flat • Convex (16” diameter or larger tubing) • Concave (36” or larger tubing) • Angled (see geometry for compatibility) • Bracket body hosts multiple fastening options • Three (3) Snap-in/SnapStak® hanger locations, duplexing allowed within capacity • Three (3) 3/8” socket connections for conduit clamps, cable blocks, ground bars, or cabinets • Magnetic units: Twelve (12) magnet units of N42 rareearth alloy composition. See calibrated testing matrix for yield-load values • HoverBOLT™ System allows bracket to be installed, adjusted and removed with command and control Material Specifications 10.2” L X 9.4” W X 2.4” H Weight: 3.74 lbs ASTM 304 Stainless Steel monolithic frame Vibratory tumble finish Spacing of bracket: Estech recommends a 5’ oncenter maximum spacing or observation of the cable manufacturer specification. In such case, the closer spacing will be the recommended value
ESTECHMAGNETICS.COM | 785-806-5211 13 ESTECH MAGNETICS PRODUCTS 2025 Magnetic Force Testing on Talon3-FLEX X&Y Axis Yield Definition Magnetic force is tested to the yield condition of the bracket embodiment. For the purpose of the calibrated testing procedure, the yield point is defined as the average maximum tension force experienced which induces a deflection along the given axis of up to .25 inches parallel to the tested steel surface. Z Axis Yield Definition The yield point is defined as the maximum tension force experienced at the vertical (90 degree / Z axis) pull of breakpoint experienced if tested perpendicular to the floor. Reporting Results from these calibrated tension forces are aggregated into a spreadsheet with each procedure as the vertical column and the axis in the horizontal column. Please see below table for product testing of the Talon3-FLEX magnetic bracket. Video of all tests further record and confirm performance data. Please refer to Estech’s Standardized Magnetic Testing Procedure Testing Program and Specifications document for further information. Table 1: Working Load Table — 2X Safety Factor Recommended by ESTECH Estech recommends a safety factor or 2X when the consumer load is compared to calibrated factory tested ultimate load data. This table below will aid in determining the correct magnetic bracket size for needed capacity. An on-center spacing of no more than 5 feet is specified on this magnetic bracket system. Table 2: Working Load Table — Performance Data Testing by ESTECH This magnetic bracket has been factory tested in a calibrated condition. Many factors influence the magnetic performance in outdoor settings such as; steel type and thickness, temperature, moisture, thickness of coating systems, coefficient of friction of coating system and direction of force. Estech has used 1/4” mild steel with a 10-12 mil AWWA compliant coating system at 70° Fahrenheit average at all stated axis and variable angular directions of tensile pull force (lbf). Magnetic force improves with; thicker steel, ferrous metal, thinner coatings, rougher coatings, colder temperatures at dry conditions. Estech formulated this calibrated test standard to best model conditions commonly seen on water tower and similar outdoor settings. Note: these are ultimate loads. Highest forces at a maximum displacement of .25” were recorded and averaged. The results are located in the table below. Table 1 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 116.5 lbf 87.5 lbf 76 lbf 76.5 lbf Y-Axis 93.5 lbf 80.5 lbf 80 lbf 88 lbf Z-Axis 83 lbf Table 2 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 223 lbf 175 lbf 152 lbf 153 lbf Y-Axis 187 lbf 161 lbf 160 lbf 176 lbf Z-Axis 166 lbf
ESTECHMAGNETICS.COM | 785-806-5211 14 ESTECH MAGNETICS PRODUCTS 2025 Talon6-FLEX Part Number: T6F-18-H Uses Magnetic fastening for cable and conduit management on indoor and outdoor steel surfaces • Common steel surfaces • Water towers • Monopoles • Wind Turbines Features • FLEX™ magnetic brackets allow the magnetic arms to pivot to a variety of surfaces without tooling • Flat • Convex (16” diameter or larger tubing) • Concave (36” or larger tubing) • Angled (see geometry for compatibility) • Bracket body hosts multiple fastening options • Six (6) Snap-in/SnapStak® hanger locations, duplexing allowed within capacity • Six (6) 3/8” socket connections for conduit clamps, cable blocks, ground bars, or cabinets • Magnetic units: Eighteen (18) magnet units of N42 rareearth alloy composition. See calibrated testing matrix for yield-load values • HoverBOLT™ System allows bracket to be installed, adjusted and removed with command and control Material Specifications 19.2” L X 9.4 W X 2.5” H Weight: 6.67 lbs ASTM 304 Stainless Steel monolithic frame Vibratory tumble finish Spacing of bracket: Estech recommends a 5’ oncenter maximum spacing or observation of the cable manufacturer specification. In such case, the closer spacing will be the recommended value
ESTECHMAGNETICS.COM | 785-806-5211 15 ESTECH MAGNETICS PRODUCTS 2025 Magnetic Force Testing on Talon6-FLEX X&Y Axis Yield Definition Magnetic force is tested to the yield condition of the bracket embodiment. For the purpose of the calibrated testing procedure, the yield point is defined as the average maximum tension force experienced which induces a deflection along the given axis of up to .25 inches parallel to the tested steel surface. Z Axis Yield Definition The yield point is defined as the maximum tension force experienced at the vertical (90 degree / Z axis) pull of breakpoint experienced if tested perpendicular to the floor. Reporting Results from these calibrated tension forces are aggregated into a spreadsheet with each procedure as the vertical column and the axis in the horizontal column. Please see below table for product testing of the Talon6-FLEX magnetic bracket. Video of all tests further record and confirm performance data. Please refer to Estech’s Standardized Magnetic Testing Procedure Testing Program and Specifications document for further information. Table 1: Working Load Table — 2X Safety Factor Recommended by ESTECH Estech recommends a safety factor or 2X when the consumer load is compared to calibrated factory tested ultimate load data. This table below will aid in determining the correct magnetic bracket size for needed capacity. An on-center spacing of no more than 5 feet is specified on this magnetic bracket system. Table 2: Working Load Table — Performance Data Testing by ESTECH This magnetic bracket has been factory tested in a calibrated condition. Many factors influence the magnetic performance in outdoor settings such as; steel type and thickness, temperature, moisture, thickness of coating systems, coefficient of friction of coating system and direction of force. Estech has used 1/4” mild steel with a 10-12 mil AWWA compliant coating system at 70° Fahrenheit average at all stated axis and variable angular directions of tensile pull force (lbf). Magnetic force improves with; thicker steel, ferrous metal, thinner coatings, rougher coatings, colder temperatures at dry conditions. Estech formulated this calibrated test standard to best model conditions commonly seen on water tower and similar outdoor settings. Note: these are ultimate loads. Highest forces at a maximum displacement of .25” were recorded and averaged. The results are located in the table below. Table 1 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 131.25 lbf 143.5 lbf 131 lbf 141.5 lbf Y-Axis 132.5 lbf 137.5 lbf 132.5 lbf 124.5 lbf Z-Axis 144 lbf Table 2 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 262.5 lbf 287 lbf 262 lbf 283 lbf Y-Axis 265 lbf 275 lbf 265 lbf 249 lbf Z-Axis 288 lbf
ESTECHMAGNETICS.COM | 785-806-5211 16 ESTECH MAGNETICS PRODUCTS 2025 Mono4-FLEX Part Number: M4F-12-H Uses Magnetic fastening for cable and conduit management on indoor and outdoor steel surfaces • Common steel surfaces • Water towers • Monopoles • Wind Turbines Features • FLEX™ magnetic brackets allow the magnetic arms to pivot to a variety of surfaces without tooling • Flat • Convex (16” diameter or larger tubing) • Concave (36” or larger tubing) • Angled (see geometry for compatibility) • Bracket body hosts multiple fastening options • Four (4) Snap-in/SnapStak® hanger locations, duplexing allowed within capacity • Six (6) 3/8” socket connections for conduit clamps, cable blocks, ground bars or cabinets • Magnetic units: Twelve (12) magnet units of N42 rareearth alloy composition. See calibrated testing matrix for yield-load values • HoverBOLT™ System allows bracket to be installed, adjusted and removed with command and control Material Specifications 13.7” L X 6.5” W X 1.8” H Weight: 4.02 lbs ASTM 304 Stainless Steel monolithic frame Vibratory tumble finish Spacing of bracket: Estech recommends a 5’ oncenter maximum spacing or observation of the cable manufacturer specification. In such case, the closer spacing will be the recommended value
ESTECHMAGNETICS.COM | 785-806-5211 17 ESTECH MAGNETICS PRODUCTS 2025 Magnetic Force Testing on Mono4-FLEX X&Y Axis Yield Definition Magnetic force is tested to the yield condition of the bracket embodiment. For the purpose of the calibrated testing procedure, the yield point is defined as the average maximum tension force experienced which induces a deflection along the given axis of up to .25 inches parallel to the tested steel surface. Z Axis Yield Definition The yield point is defined as the maximum tension force experienced at the vertical (90 degree / Z axis) pull of breakpoint experienced tested perpendicular to horizontal steel surface. Reporting Results from these calibrated tension forces are aggregated into a spreadsheet with each procedure as the vertical column and the axis in the horizontal column. Please see below table for product testing of the Mono4-FLEX magnetic bracket. Video of all tests further record and confirm performance data. Please refer to Estech’s Standardized Magnetic Testing Procedure Testing Program and Specifications document for further information. Table 1: Working Load Table — 2X Safety Factor Recommended by ESTECH Estech recommends a safety factor or 2X when the consumer load is compared to calibrated factory tested ultimate load data. This table below will aid in determining the correct magnetic bracket size for needed capacity. An on-center spacing of no more than 5 feet is specified on this magnetic bracket system. Table 2: Working Load Table — Performance Data Testing by ESTECH This magnetic bracket has been factory tested in a calibrated condition. Many factors influence the magnetic performance in outdoor settings such as; steel type and thickness, temperature, moisture, thickness of coating systems, coefficient of friction of coating system and direction of force. Estech has used 1/4” mild steel with a 10-12 mil AWWA compliant coating system at 70° Fahrenheit average at all stated axis and variable angular directions of tensile pull force (lbf). Magnetic force improves with; thicker steel, ferrous metal, thinner coatings, rougher coatings, colder temperatures at dry conditions. Estech formulated this calibrated test standard to best model conditions commonly seen on water tower and similar outdoor settings. Note: these are ultimate loads. Highest forces at a maximum displacement of .25” were recorded and averaged. The results are located in the table below. Table 1 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 110 lbf 98 lbf 104 lbf 120 lbf Y-Axis 98 lbf 87.5 lbf 95 lbf 106 lbf Z-Axis 117.5 lbf Table 2 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 220 lbf 196 lbf 208 lbf 240 lbf Y-Axis 196 lbf 175 lbf 190 lbf 212 lbf Z-Axis 235 lbf
ESTECHMAGNETICS.COM | 785-806-5211 18 ESTECH MAGNETICS PRODUCTS 2025 Mono6-FLEX Part Number: M6F-16-H Uses Magnetic fastening for cable and conduit management on indoor and outdoor steel surfaces • Common steel surfaces • Water towers • Monopoles • Wind Turbines Features • FLEX™ magnetic brackets allow the magnetic arms to pivot to a variety of surfaces without tooling • Flat • Convex (16” diameter or larger tubing) • Concave (36” or larger tubing) • Angled (see geometry for compatibility) • Bracket body hosts multiple fastening options • Four (4) Snap-in/SnapStak® hanger locations, duplexing allowed within capacity • Six (6) 3/8” socket connections for conduit clamps, cable blocks, ground bars or cabinets • Magnetic units: Twelve (12) magnet units of N42 rareearth alloy composition. See calibrated testing matrix for yield-load values • HoverBOLT™ System allows bracket to be installed, adjusted and removed with command and control Material Specifications 13.7” L X 6.5” W X 1.8” H Weight: 4.02 lbs ASTM 304 Stainless Steel monolithic frame Vibratory tumble finish Spacing of bracket: Estech recommends a 5’ oncenter maximum spacing or observation of the cable manufacturer specification. In such case, the closer spacing will be the recommended value
ESTECHMAGNETICS.COM | 785-806-5211 19 ESTECH MAGNETICS PRODUCTS 2025 Magnetic Force Testing on Mono6-FLEX X&Y Axis Yield Definition Magnetic force is tested to the yield condition of the bracket embodiment. For the purpose of the calibrated testing procedure, the yield point is defined as the average maximum tension force experienced which induces a deflection along the given axis of up to .25 inches parallel to the tested steel surface. Z Axis Yield Definition The yield point is defined as the maximum tension force experienced at the vertical (90 degree / Z axis) pull of breakpoint experienced if tested perpendicular to the floor. Reporting Results from these calibrated tension forces are aggregated into a spreadsheet with each procedure as the vertical column and the axis in the horizontal column. Please see below table for product testing of the Mono6-FLEX magnetic bracket. Video of all tests further record and confirm performance data. Please refer to Estech’s Standardized Magnetic Testing Procedure Testing Program and Specifications document for further information. Table 1: Working Load Table — 2X Safety Factor Recommended by ESTECH Estech recommends a safety factor or 2X when the consumer load is compared to calibrated factory tested ultimate load data. This table below will aid in determining the correct magnetic bracket size for needed capacity. An on-center spacing of no more than 5 feet is specified on this magnetic bracket system. Table 2: Working Load Table — Performance Data Testing by ESTECH This magnetic bracket has been factory tested in a calibrated condition. Many factors influence the magnetic performance in outdoor settings such as; steel type and thickness, temperature, moisture, thickness of coating systems, coefficient of friction of coating system and direction of force. Estech has used 1/4” mild steel with a 10-12 mil AWWA compliant coating system at 70° Fahrenheit average at all stated axis and variable angular directions of tensile pull force (lbf). Magnetic force improves with; thicker steel, ferrous metal, thinner coatings, rougher coatings, colder temperatures at dry conditions. Estech formulated this calibrated test standard to best model conditions commonly seen on water tower and similar outdoor settings. Note: these are ultimate loads. Highest forces at a maximum displacement of .25” were recorded and averaged. The results are located in the table below. Table 1 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 141 lbf 131.5 lbf 136 lbf 117.5 lbf Y-Axis 132.5 lbf 126 lbf 126.5 lbf 142 lbf Z-Axis 198 lbf Table 2 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 282 lbf 263 lbf 272 lbf 235 lbf Y-Axis 265 lbf 252 lbf 253 lbf 284 lbf Z-Axis 396 lbf
ESTECHMAGNETICS.COM | 785-806-5211 20 ESTECH MAGNETICS PRODUCTS 2025 Sidewall54-FLEX Part Number: SDWL-54-H Uses Antenna fastening on outdoor steel surfaces. These units are meant to provide reaction force and can be used in conjunction with other SidewallFLEX™ magnetic mounts • Common steel surfaces • Water towers • Wind Turbines Features • FLEX™ magnetic sidewall brackets allow the magnetic arms to pivot to a variety of surfaces without tooling • Flat • Convex (32” diameter or larger tubing) • Angled (see geometry for compatibility) • Magnetic units: Fifty-four (54) magnet units of N42 rareearth alloy composition. See calibrated testing matrix for yield-load values • HoverBOLT™ System allows bracket to be installed, adjusted and removed with command and control Material Specifications 25” L X 18.6” W X 5.7” H Weight: 36.7 lbs ASTM 304 Stainless Steel monolithic frame Spacing of bracket: Estech recommends a 5’ oncenter maximum spacing or observation of the cable manufacturer specification. In such case, the closer spacing will be the recommended value A depiction of the flexibility of the Flex™ Technology mechanism within a Sidewall54-Flex mount. An example of three Sidewall-54-FLEX on a wind turbine; a convex surface.
ESTECHMAGNETICS.COM | 785-806-5211 21 ESTECH MAGNETICS PRODUCTS 2025 Magnetic Force Testing on Sidewall54-FLEX X&Y Axis Yield Definition Magnetic force is tested to the yield condition of the bracket embodiment. For the purpose of the calibrated testing procedure, the yield point is defined as the average maximum tension force experienced which induces a deflection along the given axis of up to .25 inches parallel to the tested steel surface. Z Axis Yield Definition The yield point is defined as the maximum tension force experienced at the vertical (90 degree / Z axis) pull of breakpoint experienced if tested perpendicular to the floor. Reporting Results from these calibrated tension forces are aggregated into a spreadsheet with each procedure as the vertical column and the axis in the horizontal column. Please see below table for product testing of the Sidewall-FLEX-54 magnetic bracket. Video of all tests further record and confirm performance data. Please refer to Estech’s Standardized Magnetic Testing Procedure Testing Program and Specifications document for further information. Table 1: Working Load Table — 2X Safety Factor Recommended by ESTECH Estech recommends a safety factor or 2X when the consumer load is compared to calibrated factory tested ultimate load data. This table below will aid in determining the correct magnetic bracket size for needed capacity. An on-center spacing of no more than 5 feet is specified on this magnetic bracket system. Table 2: Working Load Table — Performance Data Testing by ESTECH This magnetic bracket has been factory tested in a calibrated condition. Many factors influence the magnetic performance in outdoor settings such as; steel type and thickness, temperature, moisture, thickness of coating systems, coefficient of friction of coating system and direction of force. Estech has used 1/4” mild steel with a 10-12 mil AWWA compliant coating system at 70° Fahrenheit average at all stated axis and variable angular directions of tensile pull force (lbf). Magnetic force improves with; thicker steel, ferrous metal, thinner coatings, rougher coatings, colder temperatures at dry conditions. Estech formulated this calibrated test standard to best model conditions commonly seen on water tower and similar outdoor settings. Note: these are ultimate loads. Highest forces at a maximum displacement of .25” were recorded and averaged. The results are located in the table below. Table 1 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 529.25 lbf 489.75 lbf 504.25 lbf 565.75 lbf Y-Axis 574.25 lbf 180.4 lbf 552.25 lbf 611.5 lbf Z-Axis 801.5 lbf Table 2 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 1,058.5 lbf 979.5 lbf 1,008.5 lbf 1,131.5 lbf Y-Axis 1,148.5 lbf 360.8 lbf 1,104.5 lbf 1,223.0 lbf Z-Axis 1,603.0 lbf
ESTECHMAGNETICS.COM | 785-806-5211 22 ESTECH MAGNETICS PRODUCTS 2025 Sidewall72-FLEX Part Number: SDWL-72-H Uses Antenna fastening on outdoor steel surfaces. These units are meant to provide reaction force and can be used in conjunction with other Sidewall mounts • Common steel surfaces • Water towers • Wind Turbines Features • FLEX™ magnetic brackets allow the magnetic arms to pivot to a variety of surfaces without tooling • Flat • Convex (38” diameter or larger tubing) • Angled (see geometry for compatibility) • Magnetic units: Seventy-two (72) magnet units of N42 rare-earth alloy composition. See calibrated testing matrix for yield-load values • HoverBOLT™ System allows bracket to be installed, adjusted and removed with command and control Material Specifications 32.4” L X 23.6” W X 16.1” H Weight: 48.7 lbs ASTM 304 Stainless Steel monolithic frame Spacing of bracket: Estech recommends a 5’ oncenter maximum spacing or observation of the cable manufacturer specification. In such case, the closer spacing will be the recommended value A depiction of the flexibility of the Flex™ Technology mechanism within a Sidewall54-FLEX mount. An example of three Sidewall-54-FLEX on a wind turbine; a convex surface.
ESTECHMAGNETICS.COM | 785-806-5211 23 ESTECH MAGNETICS PRODUCTS 2025 Magnetic Force Testing on Sidewall72FLEX X&Y Axis Yield Definition Magnetic force is tested to the yield condition of the bracket embodiment. For the purpose of the calibrated testing procedure, the yield point is defined as the average maximum tension force experienced which induces a deflection along the given axis of up to .25 inches parallel to the tested steel surface. Z Axis Yield Definition The yield point is defined as the maximum tension force experienced at the vertical (90 degree / Z axis) pull of breakpoint experienced if tested perpendicular to the floor. Reporting Results from these calibrated tension forces are aggregated into a spreadsheet with each procedure as the vertical column and the axis in the horizontal column. Please see below table for product testing of the Sidewall-FLEX-72 magnetic bracket. Video of all tests further record and confirm performance data. Please refer to Estech’s Standardized Magnetic Testing Procedure Testing Program and Specifications document for further information. Table 1: Working Load Table — 2X Safety Factor Recommended by ESTECH Estech recommends a safety factor or 2X when the consumer load is compared to calibrated factory tested ultimate load data. This table below will aid in determining the correct magnetic bracket size for needed capacity. An on-center spacing of no more than 5 feet is specified on this magnetic bracket system. Table 2: Working Load Table — Performance Data Testing by ESTECH This magnetic bracket has been factory tested in a calibrated condition. Many factors influence the magnetic performance in outdoor settings such as; steel type and thickness, temperature, moisture, thickness of coating systems, coefficient of friction of coating system and direction of force. Estech has used 1/4” mild steel with a 10-12 mil AWWA compliant coating system at 70° Fahrenheit average at all stated axis and variable angular directions of tensile pull force (lbf). Magnetic force improves with; thicker steel, ferrous metal, thinner coatings, rougher coatings, colder temperatures at dry conditions. Estech formulated this calibrated test standard to best model conditions commonly seen on water tower and similar outdoor settings. Note: these are ultimate loads. Highest forces at a maximum displacement of .25” were recorded and averaged. The results are located in the table below. Table 1 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 777.6 lbf 727.2 lbf 745.2 lbf 828 lbf Y-Axis 842.4 lbf 795.6 lbf 810 lbf 889.2 lbf Z-Axis 1,112.4 lbf Table 2 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 1,555.2 lbf 1,454.4 lbf 1,490.4 lbf 1,656.0 lbf Y-Axis 1,684.8 lbf 1,591.2 lbf 1,620.0 lbf 1,778.4 lbf Z-Axis 2,224.8 lbf
ESTECHMAGNETICS.COM | 785-806-5211 24 ESTECH MAGNETICS PRODUCTS 2025 MagFOOT-170™ Uses Magnetic support for wireless installations as part of the HaloMAG™ structure, or independently on installations as tie-back, kick-plate, and structure reinforcement (structure analysis and/or mount analysis may be required) • Common steel surfaces • Water towers Features • Factory tuned to conform to curved or domed surfaces • Magnetic units: One hundred seventy (170) magnet units of N42 rare-earth alloy composition. See calibrated testing matrix for yield-load values • All-weather resistant and corrosion mitigated • Coated with white polyurethane on top of product for heat reflection • HoverBOLT™ System allows bracket to be installed, adjusted and removed with command and control Material Specifications 17.72” L X 20.52” W X 11.25” H Weight: 81 lbs ASTM 304 Stainless Steel monolithic frame Mast: 2-3/8” OD schedule 40 aluminum, or Estech KickBLADE™ for kicker connections Field Adjustable Mag-Trays 1 2"-13 Hoverbolts Position of attachment (variable along Y-Axis) Maximum 2.5" Interior Diameter N42 Magnet Units si xA- X Y-Axis Field Adjustable Mag-Trays 1 2"-13 Hoverbolts Position of attachment (variable along Y-Axis) Maximum 2.5" Interior Diameter N42 Magnet Units si xA- Z Y-Axis Y-Axis Traverse Positions KickBLADE (Rotates 90 degrees upon Z-Axis) MagFOOT for use in Estech’s HaloMAG™ system. MagFOOT for use with Estech’s KickBLADE™ system for kicker connection supports.
ESTECHMAGNETICS.COM | 785-806-5211 25 ESTECH MAGNETICS PRODUCTS 2025 Magnetic Force Testing on MagFOOT™ X&Y Axis Yield Definition Magnetic force is tested to the yield condition of the bracket embodiment. For the purpose of the calibrated testing procedure, the yield point is defined as the average maximum tension force experienced which induces a deflection along the given axis of up to .25 inches parallel to the tested steel surface. Z Axis Yield Definition The yield point is defined as the maximum tension force experienced at the vertical (90 degree / Z axis) pull of breakpoint experienced if tested perpendicular to the floor. Reporting Results from these calibrated tension forces are aggregated into a spreadsheet with each procedure as the vertical column and the axis in the horizontal column. Please see below table for product testing of the MagFOOT™ magnetic bracket. Video of all tests further record and confirm performance data. Please refer to Estech’s Standardized Magnetic Testing Procedure Testing Program and Specifications document for further information. Table 1: Working Load Table — 2X Safety Factor Recommended by ESTECH Estech recommends a safety factor or 2X when the consumer load is compared to calibrated factory tested ultimate load data. This table below will aid in determining the correct magnetic bracket size for needed capacity. An on-center spacing of no more than 5 feet is specified on this magnetic bracket system. Table 2: Working Load Table — Performance Data Testing by ESTECH This magnetic bracket has been factory tested in a calibrated condition. Many factors influence the magnetic performance in outdoor settings such as; steel type and thickness, temperature, moisture, thickness of coating systems, coefficient of friction of coating system and direction of force. Estech has used 1/4” mild steel with a 10-12 mil AWWA compliant coating system at 70° Fahrenheit average at all stated axis and variable angular directions of tensile pull force (lbf). Magnetic force improves with; thicker steel, ferrous metal, thinner coatings, rougher coatings, colder temperatures at dry conditions. Estech formulated this calibrated test standard to best model conditions commonly seen on water tower and similar outdoor settings. Note: these are ultimate loads. Highest forces at a maximum displacement of .25” were recorded and averaged. The results are located in the table below. Table 1 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 1,659 lbf 1,009 lbf 1,218 lbf 1,181 lbf Y-Axis 1,573 lbf 1,344 lbf 1,414 lbf 1,264 lbf Z-Axis 2,767 lbf Table 2 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 3,318 lbf 2,017 lbf 2,435 lbf 2,361 lbf Y-Axis 3,145 lbf 2,687 lbf 2,828 lbf 2,527 lbf Z-Axis 5,533 lbf
ESTECHMAGNETICS.COM | 785-806-5211 26 ESTECH MAGNETICS PRODUCTS 2025 MagFOOT-248™ Uses Magnetic support for wireless installations as part of the HaloMAG™ structure, or independently on installations as tieback, kick-plate, and structure reinforcement (structure analysis and/or mount analysis may be required) • Common steel surfaces • Water towers Features • Factory tuned to conform to curved or domed surfaces • Magnetic units: Two hundred forty eight (248) magnet units of N42 rare-earth alloy composition. See calibrated testing matrix for yield-load values • All-weather resistant and corrosion mitigated • Coated with white polyurethane on top of product for heat reflection • HoverBOLT™ System allows bracket to be installed, adjusted and removed with command and control Material Specifications 25.51” L X 21.77” W X 11.23” H Weight: 116 lbs ASTM 304 Stainless Steel, dual-level frame adjustable to steel surfaces Mast: 2-3/8” OD schedule 40 aluminum, or Estech KickBLADE™ for kicker connections Field Adjustable Mag-Trays 1 2"-13 Hoverbolts Position of attachment (variable along Y-Axis) Maximum 2.5" Interior Diameter N42 Magnet Units si xA- X Y-Axis Field Adjustable Mag-Trays 1 2"-13 Hoverbolts Position of attachment (variable along Y-Axis) Maximum 2.5" Interior Diameter N42 Magnet Units si xA- Z Y-Axis Y-Axis Traverse Positions KickBLADE (Rotates 90 degrees upon Z-Axis) MagFOOT for use in Estech’s HaloMAG™ system. MagFOOT for use with Estech’s KickBLADE™ system for kicker connection supports.
ESTECHMAGNETICS.COM | 785-806-5211 27 ESTECH MAGNETICS PRODUCTS 2025 Magnetic Force Testing on MagFOOT™ X&Y Axis Yield Definition Magnetic force is tested to the yield condition of the bracket embodiment. For the purpose of the calibrated testing procedure, the yield point is defined as the average maximum tension force experienced which induces a deflection along the given axis of up to .25 inches parallel to the tested steel surface. Z Axis Yield Definition The yield point is defined as the maximum tension force experienced at the vertical (90 degree / Z axis) pull of breakpoint experienced if tested perpendicular to the floor. Reporting Results from these calibrated tension forces are aggregated into a spreadsheet with each procedure as the vertical column and the axis in the horizontal column. Please see below table for product testing of the MagFOOT™ magnetic bracket. Video of all tests further record and confirm performance data. Please refer to Estech’s Standardized Magnetic Testing Procedure Testing Program and Specifications document for further information. Table 1: Working Load Table — 2X Safety Factor Recommended by ESTECH Estech recommends a safety factor or 2X when the consumer load is compared to calibrated factory tested ultimate load data. This table below will aid in determining the correct magnetic bracket size for needed capacity. An on-center spacing of no more than 5 feet is specified on this magnetic bracket system. Table 2: Working Load Table — Performance Data Testing by ESTECH This magnetic bracket has been factory tested in a calibrated condition. Many factors influence the magnetic performance in outdoor settings such as; steel type and thickness, temperature, moisture, thickness of coating systems, coefficient of friction of coating system and direction of force. Estech has used 1/4” mild steel with a 10-12 mil AWWA compliant coating system at 70° Fahrenheit average at all stated axis and variable angular directions of tensile pull force (lbf). Magnetic force improves with; thicker steel, ferrous metal, thinner coatings, rougher coatings, colder temperatures at dry conditions. Estech formulated this calibrated test standard to best model conditions commonly seen on water tower and similar outdoor settings. Note: these are ultimate loads. Highest forces at a maximum displacement of .25” were recorded and averaged. The results are located in the table below. Table 1 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 2,546 lbf 1,437 lbf 1,692 lbf 1,283 lbf Y-Axis 2,668 lbf 1,891 lbf 1,692 lbf 1,717 lbf Z-Axis 2,807 lbf Table 2 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 5,091 lbf 2,874 lbf 3,383 lbf 2,566 lbf Y-Axis 5,336 lbf 3,782 lbf 3,383 lbf 3,433 lbf Z-Axis 5,614 lbf
ESTECHMAGNETICS.COM | 785-806-5211 28 ESTECH MAGNETICS PRODUCTS 2025 MagFOOT-322™ Uses Magnetic support for wireless installations as part of the HaloMAG™ structure, or independently on installations as tie-back, kick-plate, and structure reinforcement (structure analysis and/or mount analysis may be required) • Common steel surfaces • Water towers Features • Factory tuned to conform to curved or domed surfaces • Magnetic units: Three hundred twenty two (322) magnet units of N42 rare-earth alloy composition. See calibrated testing matrix for yield-load values • All-weather resistant and corrosion mitigated • Coated with white polyurethane on top of product for heat reflection • HoverBOLT™ System allows bracket to be installed, adjusted and removed with command and control Material Specifications 32.25” L X 21.77” W X 11.31” H Weight: 152 lbs ASTM 304 Stainless Steel, dual-level frame adjustable to steel surfaces Mast: 2-3/8” OD schedule 40 aluminum, or Estech KickBLADE™ for kicker connections Field Adjustable Mag-Trays 1 2"-13 Hoverbolts Position of attachment (variable along Y-Axis) Maximum 2.5" Interior Diameter N42 Magnet Units si xA- X Y-Axis Field Adjustable Mag-Trays 1 2"-13 Hoverbolts Position of attachment (variable along Y-Axis) Maximum 2.5" Interior Diameter N42 Magnet Units si xA- Z Y-Axis Y-Axis Traverse Positions KickBLADE (Rotates 90 degrees upon Z-Axis) MagFOOT for use in Estech’s HaloMAG™ system. MagFOOT for use with Estech’s KickBLADE™ system for kicker connection supports.
ESTECHMAGNETICS.COM | 785-806-5211 29 ESTECH MAGNETICS PRODUCTS 2025 Magnetic Force Testing on MagFOOT™ X&Y Axis Yield Definition Magnetic force is tested to the yield condition of the bracket embodiment. For the purpose of the calibrated testing procedure, the yield point is defined as the average maximum tension force experienced which induces a deflection along the given axis of up to .25 inches parallel to the tested steel surface. Z Axis Yield Definition The yield point is defined as the maximum tension force experienced at the vertical (90 degree / Z axis) pull of breakpoint experienced if tested perpendicular to the floor. Reporting Results from these calibrated tension forces are aggregated into a spreadsheet with each procedure as the vertical column and the axis in the horizontal column. Please see below table for product testing of the MagFOOT™ magnetic bracket. Video of all tests further record and confirm performance data. Please refer to Estech’s Standardized Magnetic Testing Procedure Testing Program and Specifications document for further information. Table 1: Working Load Table — 2X Safety Factor Recommended by ESTECH Estech recommends a safety factor or 2X when the consumer load is compared to calibrated factory tested ultimate load data. This table below will aid in determining the correct magnetic bracket size for needed capacity. An on-center spacing of no more than 5 feet is specified on this magnetic bracket system. Table 2: Working Load Table — Performance Data Testing by ESTECH This magnetic bracket has been factory tested in a calibrated condition. Many factors influence the magnetic performance in outdoor settings such as; steel type and thickness, temperature, moisture, thickness of coating systems, coefficient of friction of coating system and direction of force. Estech has used 1/4” mild steel with a 10-12 mil AWWA compliant coating system at 70° Fahrenheit average at all stated axis and variable angular directions of tensile pull force (lbf). Magnetic force improves with; thicker steel, ferrous metal, thinner coatings, rougher coatings, colder temperatures at dry conditions. Estech formulated this calibrated test standard to best model conditions commonly seen on water tower and similar outdoor settings. Note: these are ultimate loads. Highest forces at a maximum displacement of .25” were recorded and averaged. The results are located in the table below. Table 1 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 3,132 lbf 2,062 lbf 2,278 lbf 1,956 lbf Y-Axis 2,995 lbf 2,218 lbf 2,018 lbf 2,043 lbf Z-Axis 3,460 lbf Table 2 0º Angle 30º Angle 45º Angle 60º Angle 90º Angle X-Axis 6,263 lbf 4,123 lbf 4,555 lbf 3,911 lbf Y-Axis 5,989 lbf 4,435 lbf 4,036 lbf 4,086 lbf Z-Axis 6,919 lbf
ESTECHMAGNETICS.COM | 785-806-5211 30 ESTECH MAGNETICS PRODUCTS 2025 TripodMAX Magnetic Bracket Uses Industrial magnetic bracketing for antenna attachment • Common Antenna: radio, telemetry, wisp/internet, solar, and cellular Features • Number of magnets: one hundred five (105) • Calculated vertical pull force up to: 2,730 lbf • Calculated sheer pull force up to: 2,104 lbf • Overturning moment: 412 lbf at 52” above steel surface • Applied and removed to steel surface with patent pending HoverBOLT™ System • Incorporated patented FlexTechnology™ conforms and flexes to diameter and curvature of steel surfaces • Commonly paired with Estech Talon Series Magnetic Bracket for cable fastening • Fixed mast is adjustable to ensure that mast remains at 90 degree angle from steel surface Material Specifications Fixed mast: schedule 40 2-3/8” Fixed mast height: 52” Designed for antennae up to 125 lbs 304 Stainless Steel Monolithic Frame
